This is my Honda NTV Revere!  |
General |
|
| Make | 1992 Honda | |
| Model | NTV Revere | |
| Base Price | € ? | |
| Tyres | Dunlop Arrowmax GT501 | |
| Top speed | 188 km/h / 116.8 mph | |
|
Dimensions |
||
| Wheelbase | 1460 mm / 57.38 inch | |
| Length | 2190 mm / 86.2 inch | |
| Height | 1080 mm / 42.5 inch | |
| Width | 710 mm / 30.0 inch | |
| Seat Hight | 810 mm / 31.83 inch | |
| Weight | 208 kg / 428.56 lb | |
| Dry Weight | 188 kg / 414.45 lb | |
| Rear Tire | 150/70 - 17 inch | |
| Front Tire | 110/80 - 17 inch | |
| Fuel capacity | 19 liters / 5 gallons | |
|
Engine |
||
| Capacity | 647.00 cc (39.48 cubic inches) | |
| Type | V2, 4 stroke, 52° | |
| Valves | 3 valves per cylinder | |
| Carburetors | 2 Kei-Hin 34,4 mm | |
| Power | 60 bhp (43.8 kW) @ 7500 rpm | |
| Cooling | Pressurized cooling fluid | |
| Bore | 79.0 mm / 3.10 inch | |
| Stroke | 66.0 mm / 2.59 inch | |
| Compression | 9.2:1 | |
| Fuel | unleaded gasoline | |
|
Gear box |
||
| Type | 5 speed constant mesh foot operated |
|
| Gears | 1 - 3,083 2 - 2,062 3 - 1,550 4 - 1,240 5 - 1,074 |
|
| Final drive | shaft cardan | |
|
Brakes |
||
| Front Disc | 316 mm / 12.42 inch | |
| Rear Disc | 276 mm / 10.85 inch | |
